pure x9 solar hybrid inverter price list Huami Brand

pure x9 solar hybrid inverter price list Huami Brand

Model
YY-917S
Minimum
1PCS
Payment
TT/Other
Origin
China Guangzhou
Company Advantages
1. Our products have been successfully used in Waterproof Swimming poor solar system, Qater 60KW off grid solar system and etc. As one of the unique feature, solar hybrid inverter price list successfully makes sma hybrid inverter more popular among customers. Our products have been successfully used in Waterproof Swimming poor solar system, Qater 60KW off grid solar system and etc
2. Guangzhou Huami Solar Power Co.,ltd, well-known for its superior quality, will provide first-class service.
3. Especially designed for hybrid power inverter, hybrid inverter charger is also comfortable at the same time. Our products are qualified with SGS and CE certificates
4. We can provide OEM service for customers with such requirement. Our products have been very impressive for the performance of hybrid on grid inverter,hybrid solar inverter charger and hybrid pv inverter.
5. hybrid off grid inverter are specially designed for hybrid solar inverter system for an important function which can ensure optimal performance. The materials of Solar system include solar panel, solar inverter, solar charge controller, PV holder, Cables (DC&AC cables) and etc


undefined


/  Product Features


  •

    1. Adopt low-frequency transformer , pure sine -wave AC output , strong capacity of different load .


  •

    2.Auto voltage regulation function (AVR),wide input voltage 145V~275V , accurate output, fully AVR, adapt all kinds of adverse electric environments.


  •

    3.Intelligent battery charging the charging current can be adjusted according to different battery , fast and reliable , also prolong the working life of the battery ;


  •

    4.Intelligent LCD display output voltage , frequency , battery capacity , fault, over load ,load ect ;


  •

    5.User can RS232 or USB communication software to monitor the inverter , timing shutdown ;



undefined
undefined


  •

    6.Satisfy the power supply for different back up time ;


  •

    7.Adapt all kinds of adverse electric environments ;


  •

    8.Turn on automatically under mains supply mode, wider ranger of application ;


  •

    9.Advanced automatic constant charging circuit , prolongs battery life ;


  •

    10. Perfect full protection against under-voltage , over-load , short-circuit ect .


/  Five protections


Five Protections



1.Over Voltage protection
2.Over load protection
3.Over temperature protection
4.Short circuit protection
5.Under Voltage protection


/  Product Application


undefined

01 /
-
For off grid home system
undefined

02 /
-
For out door solar system
undefined

03 /
-
For camper
undefined

04 /
-
For power supply
undefined

05 /
-
Off grid solar plant for factory


/  Details show




Panel Button Instruction and Setting in detail

  •   Mute/Function Button:Press the button about one second .
        You will hear the rem ind voice then enter to silent Mode .
        (Still keep alarm of over-load,low battery voltage ,fault,etc)

  •   Switch button-Turn on:press button for about 3 seconds will hear remind voice then into the power on status;Turn off: press
        key for about three seconds will
        hear rem ind voice then in to the power off status.
        Turn on procedure

  •   All required cables are connected , and switch "ON" of external battery bank to "ON" position ;

  •   Press power "ON" of front panel for about 3 seconds;

  •   The user mains input switch to "ON" position ;

  •   Wait about 30 seconds until the output voltage stability;

  •   In turn connect to the load ;Shutdown Procedures

  •   Move all loads;

  •   Press power "OFF" button on front panel then turn off the inverter with built-in controller.


undefined
  •   LED (solar panel charging and DC charging indicator lights)
         LED 4 indicator light on front panel : indicate the solar panel charging capacity and battery capacity .
        When charging in daylight , 4 indicator light are flickering , will stop flickering
        when battery is charged full .
        When discharging at night , if the indicator light flickering at 25% , mean battery is almost out of power .
        If indicator light is lighted , bur no output , it mean over current , short circuit ,low voltage , over voltage etc .


/  Inverter Appearance design


undefined
350-500W
undefined
700-1000W


undefined
1500-2000W
undefined
2000-3000W


undefined
4000-6000W
undefined
7000-10000W


undefined

Wire connection diagram

++
undefined


/   product  Parameters


Model number

35112/24

50112/24

10221/48

20224/48

30224/48

20224/48

30224/48

Rated capacity

350W

500W

1000W

2000W

3000W

2000W

3000W

Input

Voltage

(140-275)VAC

Frequency

45-65Hz

Output

Voltage

AC220V ± 2%(battery mode)

Frequency

50/60Hz ± 1 %(battery mode)

Output wave form

Sine

Efficiency

>80%

Battery

Fill Electrolyte

Battery rated voltage

12/24VDC

12/24/48 VDC

24/48VDC

24/48VDC

PV Max input voltage

18/36VDC

18/36/72VDC

36/72VDC

36/72VDC

PV Max input current

10A

20A

30A

50A

Protect

Overload. short. High and low voltage protection

Conversion way

Interactive

Capacity of over load

DC mode 110%-120%maintain30S, 160%maintain300ms close

Communication port

RS -232

Operating environment

Temperature

0-40℃

Humidity

10%-90%

Size L*W*H (mm)

315*210*120

390*145*210

400*180*325

420*200*330

400*180*325

420*200*330

N.W/GW(kg)

7kg/8kg

9kg/8Kg

14kg/15kg

24kg/25kg

29kg/30kg

24kg/25kg

29kg/30kg


Model number

40248

50248/96

60296

602192

70296

702912

103192

Rated capacity

4000W

5000 W

6000W

6000W

7000W

7000W

10000W

Input

Voltage

(140-275)VAC

Frequency

45-65Hz

Output

Voltage

AC220V ± 2%(battery mode)

Frequency

50/60Hz ± 1 %(battery mode)

Output wave form

Sine

Efficiency

>80%

Battery

Fill Electrolyte

Battery rated voltage

48VDC

48/96 VDC

96VDC

192VDC

96VDC

192VDC

PV Max input voltage

72VDC

72/144VDC

144VDC

288VDC

144VDC

288VDC

PV Max input current

50A

50A

50A

50A

50A

50A

Protect

Overload. short. High and low voltage protection

Conversion way

Interactive

Capacity of over load

DC mode 110%-120%maintain30S, 160%maintain300ms close

Communication port

RS -232

Operating environment

Temperature

0-40℃

Humidity

10%-90%

Size L*W*H (mm)

457*247*440

457*247*440

485*298*646

N.W/GW(kg)

42kg

46kg

53kg

54kg

58kg

58kg

75kg
