Huami Brand sine pure inverter pwm solar charge controller manufacture
Huami Brand sine pure inverter pwm solar charge controller manufacture
Model
W10-10212/24
Minimum
1PCS
Payment
TT/Other
Origin
China Guangzhou
Company Advantages
1. With a decade industry experience, Huami Solar is a manufacturer located in Guangzhou, Guangdong province. As one of the unique feature, mppt charge controller successfully makes mppt solar charge controller more popular among customers. With a decade industry experience, Huami Solar is a manufacturer located in Guangzhou, Guangdong province
2. Guangzhou Huami Solar Power Co.,ltd, well-known for its superior quality, will provide first-class service. Our products have been successfully used in Waterproof Swimming poor solar system, Qater 60KW off grid solar system and etc
3. Excellent performances of pwm solar charge controller can be seen from 30 amp solar charge controller. All our products has a warranty
4. Following a detailed analysis and in close consultation with you, our Guangzhou Huami Solar Power Co.,ltd experts help you decide which solar charge controller price is ideally suited to your products and can be optimally integrated into an efficient end-of-line mppt solar charge controller price process. Our products can be applied to many places, such as street light, outdoor camping light and so on.
5. We are equipped with experienced and professional technical group. Huami best solar charge controller,mppt charge controller is designed with mppt solar charge controller for ease of use..

W10 series Intelligent pure sine wave inverter


undefined

Basically the function of an inverter is to convert available DC energy stored in the battery to AC energy that can be utilized at home.


/  Product Features


  •

    Inverter output power efficiency up to 85 percent;


  •

    New design of inverter external show , more convenient to install ;


  •

    Big LCD display , show parameters directly ;


  •

    Double LCD display for check the parameters more clearly ;


  •

    Suitable for more kinds of battery ;



undefined


  •

    AC bypass output ,frequency adaptive system ,AVR function;


  •

    Three working mode for choose, grid power bypass .grid power charging and ECO model;


  •

    Excellent loading ability with 3 times starting peak power crest ratio.;


  •

    Pure sine wave AC output .input and output design isolated well ;


  •

    Intelligent cooling fan design (according to the internal temperature to controller the speed of fan automatic;


  •

    Protection against under-voltage , over-voltage .over-load, short-circuit and over-temperature;


  •

    USB port, RS-232 works well with SNMP or other remote control.


/  advantages


1. two screens design

LCD display , can be connected to the screen , more intuitive for monitor , more convenient for remote manipulation .


2. perfect protection function

More than 3 times starting power , machine self protection for more secure , assured of use.


3. More stronger compatibility

Compatible with various types of battery , support various external communications interface.


/  Five protections


Five Protections



1.Over Voltage protection
2.Over load protection
3.Over temperature protection
4.Short circuit protection
5.Under Voltage protection


/  Product Application


undefined

01 /
-
For off grid home system
undefined

02 /
-
For out door solar system
undefined

03 /
-
For camper
undefined

04 /
-
For power supply
undefined

05 /
-
Off grid solar plant for factory


/  System Connect diagram



/  Details show



undefined


undefined
undefined


undefined
undefined


/   product  Parameters


Parameters

Mode W10

10212/24

15212/24

20212/24/48

30224/48

40224/48

50248

60248

Rated power

1000W

1500W

2000W

3000W

4000W

5000W

6000W

Rate battery voltage

12VDC/24VDC

12VDC/24VDC

12VDC/24VDC/48VDC

24VDC/48VDC

24VDC/48VDC

48VDC

48VDC

Machine size (L*W*Hmm)

600*315*225

484*245*212

650*315*235

Packing(L*W*Hmm)

675*375*305

580*290*260

725*375*315

N.W(kg)

15

17

25

24

28.86

44

48

50

G.W(kg)

17

19

27

26

32.86

47

51

53

Input

DC voltage

10.5-15VDC(voltage of per battery )

AC voltage

85VAC-138VAC/93VAC-150VAC/170VAC-275VAC/186VAC-300VAC

AC frequency

45Hz-65Hz

Output

efficiency

≥85%

voltage

110VAC±2%/120VAC±2%/220VAC±2%/240VAC±2%

frequency

50/60Hz±1%

Wave form

Pure sine wave

AC voltage

220VAC±10%

AC frequency

Auto Tracking

Transfer time

≤4ms

Display

LCD display

Thermal methods

Forced Air Cooling

≤42℃ fan rotates slowly to ≥50℃ fan rotates fast

Working mode

AC fist/PV first/Energy Saving Mode

Type of battery

LEAD,OP-LE,LITHIUM;

Protection

Overload/over-current/short circuit/over temperature

Communication

RS232/RS485(optional)

Environment

Temperature

-10℃-40℃

Noise

≤55db

Humidity

<95%,without condensation






Company Features
1. Fully specialized in the R&D and production of pwm solar charge controller, Guangzhou Huami Solar Power Co.,ltd is globally recognized.
2. There is strict testing for quality of solar charge controller price to make satisfying products for customers.
3. Our best solar charge controller have been well sold to all over the world known as its mppt charge controller. Call now!
