Hot mppt solar charge controller 36v hm10a 12v24v48v charge Huami Brand
Hot mppt solar charge controller 36v hm10a 12v24v48v charge Huami Brand
Brand
Huami
Model
HME-10
Minimum
1PCS
Payment
TT/Other
Origin
China Guangzhou
Packaging Detail
Carton Packing
OEM Service
Available
Certifications
SGS, CE, RoHS
Company Advantages
1. mppt solar charge controller 36v are all in good order to ensure the well operation of pwm based solar charge controller. We can guarantee 25 years power Output Voltage for Solar panel
2. Over the years, Guangzhou Huami Solar Power Co.,ltd has developed from focusing on quality to leading breakthrough in pwm solar power controller industry. Our products can be applied to many places, such as street light, outdoor camping light and so on
3. Keeping in mind the diverse requirements of our clients, we are engaged in providing wide range of pwm 30a solar charge controller. We are equipped with experienced and professional technical group


undefined


/  SIX Functions
undefined

SIX Functions



Short Circuit Protection: In case of short circuit, Fuse work-effectively to protect equipment isn't damaged

Open Circuit Protection :When open circuit controller will protect the components

Over Current Protection :When over current controller will cut off to protect the equipment

Overcharge Protection: When the battery full charge controller will stop charging

Over-discharge Protection: When the voltage of battery lower than normal range , controller will stop discharging

Reverse Protection: Use characteristic of diode to protect the component


/  application


undefined
DC solar system
undefined
Charged for digital product
undefined
Solar lighting system


undefined
Solar home system
undefined
Solar bill board
undefined
Solar lighting box


/   product  Parameters


Type

Output Current

External Package Size

N.W.

G.W.

Qty per Carton

Voltage

Max

HME-10

12V

10A

49.0X32.0X23.0CM

7.0Kg

8.5Kg

50PCS/CTN

HME-15

12V

15A

49.0X32.0X23.0CM

7.5Kg

9.0Kg

50PCS/CTN

HME-20

12V

20A

49.0X32.0X23.0CM

8.0Kg

9.5Kg

50PCS/CTN

HME-30

12V

30A

49.0X32.0X23.0CM

8.5Kg

10.0Kg

50PCS/CTN


Rated voltage

12V

Rated current

10A

15A

20A

30A

model

HME-10

HME-15

HME-20

HME-30

Voltage of panel

≤50V

Charging model

PWM mode

Under-voltage protection

10.7V

Under-voltage recovery

12.6V

Floating voltage

13.7V

Terminal

>3# AWG (<16㎡)

Storage temperature

-30℃~70℃

Humidity

≤90%

Open circuit current

<30mA

Working temperature

-20℃~50℃


Solar panel→solar controller→DC loading

                ↓

            Solar inverter

                ↓

               Appliances



 PS: Suggest to choosing solar inverter.

If the inverter not for solar system, it would be burned or alarm




/  Intelligent control



Intelligent control :
-
Base on professional control system, adopt technical chip and software realize optimized SOC control
undefined

Over charge protection:
-
controller will adopt control program to check battery and load full charging or not
undefined

Suitable for battery temperature profile:
-
temperature compensation adopt high quality sensor more accurate
undefined

Long service life:
-
adopt imported IC component, high quality MOS tube and high quality material.
undefined

Automatic-learning:
-
In case of cut off , the parameter of controller will not disappear .


/  Internal details


undefined
Imported IC component


Safe, simple , convenience
New terminal design
Efficiently thermolysis
Effectively extend the service life


undefined
Humanization Design


More convenient
High quality


undefined
Imported PC material


Inflaming retarding shock resistance
High performance anti-aging component.


/  Products show







Company Features
1. With outstanding quality of mppt solar charge controller 36v, Guangzhou Huami Solar Power Co.,ltd leads the pwm based solar charge controller market development and has created industry benchmarks.
2. Call! Do You Want Some Really Great Deals On pwm solar power controller, mppt solar charge controller kit, 12v solar charge controller circuit? Choose Huami As Your Long-Term Supplier. If You Think Our Proposal Are Acceptable, Please Let Us Have Your Order At Early Date.
3. Huami places customer service at the heart of everything we do. Get Price!
